Basic Info.
| Model NO. | TLAT2000DM-P |
| Material | Cu3 or SS316 |
| Blades | 3,4,5 or 7 |
| Certification | ISO90012000, BV |
| Transport Package | Wooden Box |
| Trademark | Thrustleader |
| Origin | China |
| HS Code | 8487100000 |
| Production Capacity | Over 100sets/ Year |
Packaging & Delivery
| Package Size | 2600.00cm * 1600.00cm * 2000.00cm |
| Package Gross Weight | 50000.000kg |
Product Description
Basic Info.
| Model No. | TLAT | Blade Quantity | 3,4,5 or 7 | |
| Driven Type | E-motor/Hydraulic motor/Diesel engine | Installation type | L-Drive,Z-Drive | |
| Lead time | 1-5 months | Certificate | CCS/DNV-GL/ABS/BV/RINA/LR/CR/RMRS | |
| Transport package | Wooden box | Weight | 300-3000kg | |
| Trademark | Thrustleader | Orginal | Jiangsu, China | |
| HS Code | 8487100000 | Produce Capacity | Over 100 sets per year |
The deck mounted azimuth thruster is a containerized thruster propulsion system that can be placed right on the deck of the vessel or barge. The compact structure, high mobility and easy installation make it very suitable fo r barges, ferries and jack-up vessels. The whole unit can be installed directly on the deck, and it can be equipped a lifting and swing up function.
Features
Compact design and reliable performance
Propeller can be driven by electric motor, diesel engine and hydraulic motor.
Hydraulic system is available.
It can be equipped with a lifting amd swing up function.
The whole unit can be installed on the deck.
Application
Typical applications for self-propelled barge, cable laying dynamic positioning barge, crane or dredger barge, ferry, river vessel and so on.
Specifications
Deck Mounted Azimuth Thruster
| Type | Max power (kW) | Normal Input speed(rpm) | Propeller Diameter(mm) |
| TLAT50DM | 40 | 1800/1500 | 300-500 |
| TLAT80DM | 60 | 1800/1500 | 400-600 |
| TLAT100DM | 75 | 1800/1500 | 450-800 |
| TLAT150DM | 110 | 1800/1500 | 500-900 |
| TLAT250DM | 185 | 1800/1500/1000 | 800-1100 |
| TLAT350DM | 260 | 1800/1500/1000 | 650-1200 |
| TLAT450DM | 350 | 1800/1500/1000 | 900-1300 |
| TLAT600DM | 450 | 1800/1500/1000 | 1100-1500 |
| TLAT850DM | 670 | 1800/1500/1000 | 1300-1650 |
| TLAT1000DM | 750 | 1800/1500/1000/750 | 1400-1750 |
| TLAT1200DM | 900 | 1500/1000/750 | 1500-1800 |
| TLAT1400DM | 1050 | 1500/1000/750 | 1600-1950 |
| TLAT1600DM | 1200 | 1500/1000/750 | 1700-2000 |
| TLAT1800DM | 1350 | 1500/1000/750 | 1800-2100 |
| TLAT2000DM | 1500 | 1000/750 | 1900-2300 |
| TLAT2200DM | 1650 | 1000/750 | 2000-2500 |
| TLAT2400DM | 1800 | 1000/750 | 2100-2600 |
| TLAT2700DM | 2000 | 1000/750 | 2200-2700 |
| TLAT3000DM | 2250 | 1000/750 | 2300-2800 |
Certificate
About us
The European brand "Dutch Thrustleader" started in Holland in 2007. To meet the growing customers, demand, and company's continuous development, DUTCH THRUSTLEADER MARINE PROPULSION(JIANGSU) CO., LTD was founded in 2017. This company houses the R&D, engineering and manufacturing using the high developed Chinese manufacturing resources.
Our company's production area is around 10000 square meters and is equipped with a specialized assembly and testing workshop. It is certified with a GB/T19001-2016/IS09001, 2015 CCS quality system certification and a BV-Factory Accreditation certificate. Our R&D center is supported with two postdoctoral professor advisors, dozens of European and Chinese senior engineers.
We design and manufacture Tunnel thrusters, Azimuth thrusters, Deck mounted azimuth thrusters, Retractable azimuth thrusters, together with advanced thruster control systems. Our thruster products range with powers from 30kW up to 6000kW. We can integrate and deliver our thruster systems with dynamic positioning systems.
For the renewable market we deliver battery power propulsion systems, hybrid electric propulsion systems, unmanned vessel control systems and on special request pod thrusters.
All propulsion projects can be delivered under approval of major classification societies like: CCS, RMRS, ABS, BV, RINA, NK, DNV-GL, LR, CRS.
Our goal is to make Dutch Thrustleader Marine Propulsion a World Class Brand. Highly customer focused, reliable and innovative.
Why choose us?
- Our Azimuth Thrusters are designed for maximum efficiency and performance.
- Our customers can trust us to provide reliable shipping and delivery services.
- Count on us to deliver Azimuth Thrusters that deliver superior performance.
- We have built strong relationships with our customers around the world, and we pride ourselves on our commitment to excellence in everything we do.
- We specialize in manufacturing Azimuth Thrusters that are both reliable and cost-effective.
- Our company has a complete processing system, from material selection to product molding to grinding, and quality inspection must be strictly controlled. We strive to make the function and appearance of Container Boat Azimuth Thruster excellent. Strict factory testing provides a further guarantee of our quality!
- We have the expertise and experience to produce Azimuth Thrusters that stand out from the competition.
- We are constantly improving our product offerings.
- Our Azimuth Thrusters are designed to meet the demands of the marine industry.
- We offer a wide range of financing and payment options to make it easy for our customers to do business with us.
Introducing our Container Boat Azimuth Thruster, a reliable and high-quality propulsion system designed for vessels of all sizes. Our thruster is specifically made for container boats, offering exceptional performance and maneuverability in various maritime conditions. With a focus on efficiency and long-term durability, our product is the ideal choice for merchants looking to enhance the capabilities of their fleet.
**High Performance:**Our thruster is engineered to deliver exceptional power and efficiency, ensuring smooth operation and precise control for container boats of all sizes. With a focus on performance, our product is designed to meet the demanding requirements of modern maritime operations.
**Reliability:**At our manufacturing facility in China, we prioritize quality and reliability in every aspect of our production process. Our Container Boat Azimuth Thruster is built to withstand the rigors of daily use, providing merchants with a dependable propulsion solution that they can rely on in any situation.
**Easy Installation:**Our thruster is designed for easy installation, allowing merchants to quickly and efficiently upgrade their vessels without the need for extensive downtime or costly modifications. With a user-friendly design, our product can be easily integrated into existing propulsion systems, making it a hassle-free solution for merchants.
**Customization Options:**We understand that every vessel is unique, which is why we offer customization options for our Container Boat Azimuth Thruster. Merchants can choose from a range of configurations and specifications to ensure that our product meets their specific requirements and performance goals.
**Cost-Effective Solution:**Our thruster offers merchants a cost-effective solution for enhancing the performance and maneuverability of their container boats. With a focus on efficiency and long-term durability, our product is a smart investment for merchants looking to optimize their fleet without breaking the bank.
**Exceptional Customer Support:**At our company, we pride ourselves on providing exceptional customer support to our merchants. From initial inquiries to post-purchase assistance, our team is dedicated to ensuring that every merchant receives the guidance and support they need to maximize the benefits of our Container Boat Azimuth Thruster.
In conclusion, our Container Boat Azimuth Thruster is a reliable, high-performance propulsion solution that is designed to meet the needs of merchants operating container boats. With a focus on performance, reliability, and cost-effectiveness, our product is the ideal choice for merchants looking to enhance the capabilities of their fleet. Contact us today to learn more about how our thruster can benefit your maritime operations.
Hot Tags: container boat azimuth thruster, China container boat azimuth thruster manufacturers, suppliers, factory, CRS Deck Mounted Azimuth Thruster, L Drived Well Mounted Azimuth Thruster, RMRS Approval Deck Mounted Azimuth Thruster, Counter Rotating Propellers Azimuth Thrusters, NK Deck Mounted Azimuth Thruster, Electrical Azimuth Thruster with Fixed Pitch
Project case
